AutoMastery Virtual Lab

📖 Help & Database (DBC)

Instruction: Use the Power Mode Slider (IGN) and Manual Gears (1-5) to drive.

ID	Message Name	Signal / Byte Layout Description
0x100	Engine_Data	• Byte 0-1: Engine Speed (RPM) • Byte 2: Vehicle Speed (km/h) • Byte 3: Gear (0=N, 1-5=Gear, 6=Rev)
0x200	Body_Status	• Byte 0: Door (00/01) • Byte 1: Indicator (00/02/03) • Byte 2: Headlight (00/01) • Byte 3-6: Windows (FL, FR, RL, RR)
0x7E0	Diag_Req	• UDS Request from Tester.
0x7E8	Diag_Res	• UDS Response from ECU.

Manual Transmission: Speed is calculated via Gear Ratio x RPM. (1=Low speed, 5=High speed).
Power Modes: OFF (Dead), ACC (Windows only), IGN (Full System).

Power Mode (IG Switch)

OFF ACC IGN

System OFF. No Power.

Manual Transmission

Engine Speed (RPM)

0 RPM ⚠️ IGNITION REQUIRED

Vehicle Speed (km/h) 0 km/h (Calculated by Gear x RPM)

Body Controls

◀

🚪

☀

▶

KM/H

RPM

CAN / Ethernet Log

Sequential

Time	Ch	ID (Hex)	Name	Dir	DLC	Data
